FoxESS Hybrid Inverter 6kW

FoxESS Hybrid Inverter 6kW

R22,000.00 ex VAT

6000 watt 1-phase on grid tie solar inverter has wide input voltage range, high MPPT efficiency more than 99%, converting 180-500 volt to 220/ 230/ 240 volt. Affordable price pure sine wave inverter, factory wholesale and free shipping to your city.

SKU: FoxESS_Inv_6kW Categories: , Tags: , ,

Description

FoxESS 6000W Single Phase, Three MPPT Hybrid inverter with Wifi, EPS

Highly Flexible

  • Able to supply a wide range of continuous backup power in the event of a grid outage
  • Generates 120/240V backup power without an external autotransformer
  • Compatible with multiple battery brands, providing up to 150kWh of storage capacity per inverter
  • Multiple energy storage working modes to satisfy various use cases and lifestyles
  • Allows up to ten (10) inverters to be stacked in parallel for maximum scalability and flexibility

Efficient Performance

  • Maximum PV input current up to 16A per string
  • Generates up to 50A/11.4kW of continuous backup power with up to 76A for ten seconds
  • Backup transfer (switch) time is <10ms
  • DC to DC battery charging for optimal use of PV-generated energy
  • Optional module-level optimization & monitoring

Intelligent Design

  • SunSpec modbus certified with the latest SunSpec models
  • Supports operation in parallel with a generator and allows teh generator to function as the grid source if utility power is lost
  • Optional integrated revenue-grade meter and external energy meter for production & consumption monitoring and export power control
  • Offers all of the smart inverter functions detailed in IEEE 1547-2018
  • Utilizes an energy management system that maximizes efficiency and offers multiple modes of operation for performance customization
  • SolisCloud allows for remote system troubleshooting, firmware upgrading, and configuration, reducing O&M costs
  • Bi-direcitonal capacity can allow the battery to charge from the grid

Safe and Reliable

  • UL 1741SA/SB and UL9540 certified
  • California Rule 21 and HECO rule 14H Compliant
  • Sophisticated alarm system ensures the system operates only under safe conditions and warns you immediately if there is an issue
  • Third-party tested and validated for product reliability
  • A stardard 10-year standard warranty is included
  • NEC 2020 compliant with various integrated RSD transmitter options are available for module-level rapid shutdown
  • External RSD & Emergency power off switch options are also available

Additional information

Weight 30 kg
Dimensions 490 × 838 × 220 mm

Product Specs

Model ATO-TL6000
Max. DC Input Power 6500 watt
Max. DC Input Voltage 500V DC
Max. DC Input Current 28A
MPPT Tracking Voltage Range 180-500V
MPPT Tracking Number / Each Input String Number 1/2
Power ON / OFF Voltage 200V / 100V
Input Terminal MC4
AC Output Power 6000W
Output Range Single phase AC 190~270V
Adjustable according to different countries and regions requirement.
Rated Voltage L+N+PE 220V/ 230V/ 240V AC
Phase Single phase (L1+L2) / Spilt phase (L1, L2+N), L1+L2=240V AC, L1+N=120V AC, L2+N=120VAC
Maximum Current 27A
Output Terminal Connect terminals
Display LCD dispaly
Protection Functions DC input switch, Anti-island, Output over-current, Input reverse connection, DC/AC surge protection, Insulation resistance testing, RCD testing, Upgrade WiFi
Certificate CE / G83 / IEC / TUV / SAA
Warranty 5 years

Physical Specs

Dimensions (L x W x H) 490 × 838× 220mm
Weight 30kg
