R1,500.00 ex VAT
VC-1220, 12.8V DC, 20Ah, Lithium Xcube Battery with BMS
| Weight | 31.5 kg |
|---|---|
| Dimensions | 520 × 270 × 220 mm |
| Model | VC 1220 |
| Nominal Battery Voltage | 12.8 V |
| Nominal Capacity | 200Ah |
| Rated Energy | 2560Wh |
| BMS Function | Overcharge, over-discharge, overcurrent and temperature protection |
| Recommended Charge Voltage | 14.4-14.6V |
| Discharge Cut-off Voltage | 10.8V |
| Standard Charge Current | 50A |
| Max. Charge Current | 100A |
| Continuous Discharge Current | 100A |
| Peak Discharge Current | 400A @5S |
| Voltage Configurations | 12,24,36 or 48V |
| Maximum Configuration | Incerse capacity in series or increasing voltage parallel |
| Maximum Time Between Charges | 3 Months |
| Dimensions (L x W x H) | 520 x 270 x 220mm |
| Weight | 31.5kg |
